Dangerous Music LIAISON

Recall Your Analog Patches Instantly. Programmable patching in analog has never been easier. With the LIAISON from Dangerous Music, store and recall complex analog patches that include up to six stereo or mono analog paths. Experience the ease of digital plug-ins with your analog rig!

Features

• Hand built in the USA
• Audiophile-grade components throughout
• Chris Muth designed analog circuits
• Six stereo insert loops with true-bypass
• Two independent stereo busses
• Parallel processing loop on Buss B
• Four monitor outputs for pre- and post-insert monitoring of both busses
• Instant A/B comparisons in the analog realm
• Four onboard memory slots for instant recall of patches
• Seamless integration with the Dangerous MASTER or another LIAISON

Short-term Memory Benefits

Make useful judgements with no gap in comparisons between sounds. The LIAISON enables A/B comparisons in the analog realm that are far easier and actually useful, eliminating the guesswork from critical decisions.

Complex Patching Made Easy and Programmable

Previously complex patches of analog equipment are made simple and instantly recalled with sophisticated signal routing and user interface.

Six Insert Loops

The LIAISON features six high-grade stereo insert loops, each switchable in and out of the signal path at the touch of a button. Use “Flip” switches for immediate auditions of new routing possibilities.

Two Main Busses

Route different analog gear chains simultaneously with two main stereo busses (A & B), or chain them together for greater versatility.

Parallel Processing Loop

Blend processed and unprocessed signals seamlessly with the onboard parallel processing loop, allowing for creative uses of analog gear without latency.

Four Monitor Channels

Monitor before or after the insert loop on each buss, maximizing your ability to make fast, reliable comparisons.

Programmability and Signal Path

Store patches for instant recall, utilize the transparent and robust analog relay switching system, and benefit from true A/B comparisons without coloration or latency.

Stay Nimble, Stay Analog

With the LIAISON, unleash your creativity in the analog environment with programmable patches, hassle-free rerouting, and instant A/B comparisons.

• Frequency Response (Passive Section): +0, -0.1dB from 10Hz to 100kHz
• Frequency Response (Active Section): +0, -0.1dB from 10Hz to 100kHz
• Maximum Level: > +28dBu
• Noise Floor: < -94.5dBu (22Hz-22kHz bandwidth)
• THD+N: < 0.002%
• IMD: < 0.003%
• Crosstalk Rejection (Passive Section): > 124dB
• Crosstalk Rejection (Active Section): > 113dB
• Input Impedance: 20K Ohms
• Output Impedance: 20 Ohms
• Replacement Fuses: USA 500mA fast blow for 120V; Europe 250mA fast blow for 240V
• Warranty: Free 2-year extended warranty with online registration. Standard Warranty: 90 days parts and labor, subject to inspection. Does not include damage incurred through abusive operation or modifications/attempted repair by unauthorized technicians.
