2-way passive studio monitor

Experience exceptional audio clarity with ATC’s high-performance 2-way studio monitor, harnessing ATC’s exclusive Constrained Layer Damping (CLD) technology. Their CLD bass/mid driver boasts a multi-layered composite cone, featuring a central damping layer that effectively minimizes cone breakup effects. This results in a remarkable drive unit that maintains exceptional clarity even at high volume levels.

ATC’s SH25-76 tweeter stands out with its exclusive dual suspension design, which maintains piston-like movement of the voice coil former without relying on Ferrofluid. This design choice guarantees consistent performance over extended periods, ensuring lasting quality.

Perfectly tailored for:

  • Precise near-field listening in any control room setting.
  • Ideal for LCR and surround monitoring in compact to mid-sized control rooms.

Key Features

  • ATC’s Exclusive Constrained Layer Damping (CLD) Technology
  • Multi-layered Composite Cone
  • ATC SH25-76 Tweeter with Dual Suspension Design
  • Drivers: HF ATC 1˝/25mm dual suspension Soft Dome (SH25-76 6 Ohm), LF ATC 6˝/150mm Constrained Layer Damping (CLD) (SB45-150CLD 8 Ohm)
  • Amplitude Linearity: 80Hz – 16kHz (+/-2dB)
  • Cut Off Frequencies: 56Hz – 22kHz (-6dB freestanding)
  • Dispersion: ±80° Coherent Horizontal, ±10° Coherent Vertical
  • Maximum Continuous SPL: 108dB (per pair @ 1m)
  • Crossover Frequency: 2.2kHz
  • Recommended Power Amplifier: 75 to 300 Watts
  • Nominal Impedance: 8 Ohm
  • Connectors: Binding Posts/4mm Plugs, bi-wire
  • Cabinet Dimensions (HxWxD): 400x238x235mm/15.7˝x9.4˝x9.3˝
  • Weight: 11kg/24lbs (per cabinet)
