Barefoot Sound Footprint 01 Gen2 3-Way Active Studio Monitor

The Footprint 01 Gen2 is a ground-up reimagining of one of Barefoot Sound’s most respected studio monitors, designed to deliver greater resolution, headroom, and real-world translation than ever before. Built for modern production environments, it brings flagship Barefoot performance into a format that works just as well in stereo mixing rooms as it does in immersive and Atmos-based studios.

Next-Generation Performance, Refined

While the original Footprint 01 established a new benchmark for compact professional monitors, the Gen2 version advances the platform with a fully tri-amplified 3-way architecture. Each driver is powered by its own dedicated Class D amplifier, allowing the system to operate with greater efficiency, lower distortion, and improved dynamic control across the entire frequency spectrum.

Reengineered Drivers with Dual-Force Low End

At the core of the Footprint 01 Gen2 is a newly developed driver set, including a dual ring radiator tweeter, a 5-inch aluminum cone midrange, and dual 8-inch aluminum cone woofers. The woofers are integrated using Barefoot’s Dual-Force technology, mounting them in direct opposition to cancel cabinet vibration at the source. The result is tighter bass, improved transient response, and a more stable, focused soundstage.

SPOC Conversion and Advanced DSP

The updated DSP platform incorporates Barefoot’s patented Spectrally Optimized Conversion technology, which places analog crossover filtering ahead of digital conversion. This approach preserves high-frequency detail, improves signal-to-noise performance, and delivers higher effective resolution with ultra-low latency. Imaging is more precise, bass extension is deeper and more controlled, and translation to the outside world becomes more predictable.

MEME Voice Emulation

The Footprint 01 Gen2 includes Barefoot’s MEME voice emulation, allowing you to instantly switch between multiple monitoring perspectives. From a precise flat reference to voicings inspired by classic mix cubes, familiar white-cone nearfields, and consumer hi-fi systems, MEME lets you evaluate how your mix will translate without changing speakers or moving from your listening position.

Refined Cabinet Design

The sealed cabinet has been acoustically refined with increased internal volume, improved bracing, and full acoustic damping throughout. Constructed from medium-density fiberboard using stress-assembly techniques, the enclosure minimizes resonance while maintaining rigidity. A textured gray polyester finish completes the clean, professional aesthetic and contributes to long-term durability.

Designed for Stereo and Immersive Studios

Whether used as a high-end nearfield, main monitor, or as part of a multi-channel immersive system, the Footprint 01 Gen2 delivers consistent performance and reliable translation. Its balance of size, output, and precision makes it a versatile choice for modern music production, post-production, and Atmos workflows.

Key Features

• Tri-amplified 3-way active studio monitor.
• Dual-Force opposing 8-inch aluminum cone woofers.
• Dedicated Class D amplification for each driver.
• SPOC conversion with advanced low-latency DSP.
• MEME voice emulation for multiple reference perspectives.
• Sealed cabinet design with refined internal bracing and damping.

Technical Specifications

• Frequency Response: 36 Hz – 40 kHz (±3 dB), 39 Hz – 30 kHz (±1 dB).
• Maximum SPL: ≥113 dB continuous.
• Crossover Frequencies: 170 Hz / 3600 Hz.
• Analog Inputs: Balanced XLR and TRS.
• Input Impedance: 20k ohms.
• Input Sensitivity: 90 dB @ 1 meter with -15 dBV input.

Amplification and Drivers

• Tweeter: 1-inch dual ring radiator with rear waveguide chamber.
• Midrange: 5-inch aluminum cone with high magnetic flux motor.
• Woofers: Dual 8-inch aluminum cone drivers.
• High-Frequency Amplifier: 60W.
• Mid-Frequency Amplifier: 150W.
• Low-Frequency Amplifier: 500W.

Power and Physical Specifications

• AC Power Input: 100–240 VAC universal.
• Power Consumption: 35W idle, 900W maximum.
• Dimensions (H × W × D): 14.25 × 10.20 × 13.63 inches.
• Weight: 40.4 lbs per speaker.
