Chameleon Labs 7603 X-Mod Features
- UK Carnhill Transformers: Features Carnhill UK microphone and line input transformers and Carnhill UK output transformer, all with mu-metal housings.
- Discrete Class A Design: High-resolution, low-noise circuitry for pristine audio.
- Hi-Z Direct Input: Front panel TRS input for instruments like guitars.
- Inductor-Based EQ: Three-band EQ with adjustable high-pass, low, mid, and high frequencies.
- Selectable Mic Impedance: 300Ω or 1200Ω settings for optimal microphone matching.
- Precision VU Meter: Custom ballistics for accurate input/output monitoring.
- Universal Power Supply: Onboard switch-mode power supply for worldwide compatibility.
Description
The Chameleon Labs 7603 X-Mod retains the exceptional dynamics and low distortion of the 7603 while introducing the unique sonic character of Carnhill’s legendary English components. This pre-amplifier is perfect for artists and engineers seeking both versatility and vintage tonal quality.
With its custom-designed transformers and inductor-based EQ topology, the 7603 X-Mod delivers superior performance while preserving the musicality associated with classic designs. The unit’s flexibility and precise control make it an indispensable tool for any studio setup.
Specifications
User-Controlled Functions:
- Mic Impedance: Switchable between 300Ω and 1200Ω for mic matching.
- 48V Phantom Power: Switchable phantom power for condenser mics.
- Direct Input: 100kΩ input sensitivity for instruments.
- Polarity Switch: Reverse the polarity of the audio signal.
- High-Pass Filter: Adjustable at 40Hz, 80Hz, 160Hz, and 320Hz.
- EQ Controls: Low, mid, and high-frequency adjustments with inductor-based design.
- Gain Adjustment: Mic boost (+20dB to +70dB) and line level (-30dB to +20dB).
- VU Meter: Monitor input/output levels with overload indicators.
Audio Specifications:
- Frequency Response: 10Hz – 20kHz (-0.5dB), 10Hz – 50kHz (-1dB).
- Maximum Output: +28dBu into 600Ω load.
- Signal-to-Noise Ratio: 116dB at maximum output.
Inputs:
- Microphone: Transformer balanced, RF isolated.
- Line: Transformer balanced, RF isolated.
- Direct Input: High impedance (100kΩ).
Mechanical:
- Build: 1RU steel enclosure with an aluminum front panel.
- Graphics: Laser etched for durability.
- Knobs: Milled aluminum for precision control.
Power Supply
100V – 240V (50/60Hz) switch-mode power supply with 3A peak output capability and low power consumption.
