Drawmer MC3.1 Monitor Controller

Drawmer MC3.1: Ultimate Control, Accurate & Transparent Monitoring

The Drawmer MC3.1 Monitor Controller builds on the success of the MC2.1, offering the same high level of accuracy and transparency with an expanded feature set. The MC3.1 faithfully reproduces what has been recorded without coloring the sound, featuring more inputs, better control, extended channel routing, and a convenient desktop wedge form factor.

The Ultimate Feature Set

The MC3.1 features a combined digital AES/SPDIF (24-bit/192kHz) input, giving a total of five individually switchable sources, including a front-panel auxiliary input with level control for easy connection of MP3 players, smartphones, or tablets. Full cue mix facilities with level control provide separate source selection for main or cue outputs and two headphone amplifiers, allowing an artist to listen to a completely different mix from the engineer. A dedicated cue mix output is also included for added flexibility.

Preset Volume Control for Consistency

A secondary preset volume control on the front panel allows for repeatable calibrated output levels for the monitors. This feature ensures that the engineer can listen to the mix at a predetermined volume time after time without meticulously adjusting the volume controls.

Comprehensive Connectivity

The MC3.1 features three stereo balanced speaker outputs, plus a dedicated mono speaker/sub-woofer output, each with individual left/right trims located underneath the unit for precise level matching. Each speaker output can be switched individually or simultaneously, allowing for versatile configurations, including listening to multiple speakers with the same sub-woofer or turning off the sub-woofer entirely.

Expanded Mix Checking Capabilities

Additional mix checking capabilities include low, mid, and high solo switches to help evaluate how different frequency ranges interact in the mix. The MC3.1 also features a left/right channel swap, built-in talkback with internal or external mic options, and footswitch operation for enhanced usability during sessions.

Tough & Secure Build Quality

With a rugged steel chassis and high-quality components, the MC3.1 is built to withstand the knocks and bumps of the studio environment. Its smart and stylish design, combined with its durability, ensures that it will last for years to come.

Accurate Sound Reproduction

For Drawmer monitor controllers, accuracy is paramount. The active circuit design of the MC3.1 faithfully reproduces the audio signal while eliminating issues commonly associated with passive circuits. You can rely on the MC3.1 for an accurate representation of your audio, ensuring that what you record is exactly what you hear.

Features

  • Ultra low noise and transparent circuit design for high fidelity sound.
  • Source switches for both Main & Cue can be active in any combination. Five inputs in total: one digital AES/SPDIF Neutrik XLR/JACK COMBI, two balanced analog Neutrik XLR/JACK COMBI, one stereo RCA analog on the rear panel, and one 3.5mm front-panel AUX.
  • Three speaker outputs plus a mono sub that can be switched individually or used for A/B comparisons. Each has level trims for precise channel matching.
  • Timed relay protection on all speaker outputs to prevent power-up/down bangs.
  • Volume can be set via the variable front-panel knob or a preset control, both featuring parallelled custom quad pots for excellent channel matching and smooth operation.
  • Two headphone amplifiers with individual level controls and switching between main and cue inputs, allowing the artist to listen to a different mix from the engineer.
  • Front-panel 3.5mm AUX input with level control for connecting MP3 players, smartphones, or tablets.
  • Cue level control adjusts the volume for the artist’s monitors.
  • Built-in talkback with level control, internal or external microphone options, desktop or footswitch activation, mono output jack, and internal routing to headphone and cue outputs.
  • Comprehensive mix checking facilities including low, mid, high solo, dim, L/R mute, and phase reverse help check every aspect of the mix.
  • Desktop wedge form factor for convenient use in any studio setup.
  • Kensington security slot (K-Slot) for added security.
  • Rugged steel chassis with a stylish brushed aluminum cover.
Description Value
Input: Maximum Input Level 27dBu
Output: Maximum Output Level before clipping 27dBu
Dynamic Range @ unity gain >117dB
Crosstalk L/R @ 1kHz >84dB
Adjacent Input Crosstalk >95dB
THD & Noise (unity gain, 0dBu input) 0.003%
Frequency Response (20Hz-20kHz) +/- 0.2dB
Phase Response (20Hz-20kHz) +/- 2 degrees
Power Requirements External Power Supply: Input 100-240V ~ 50-60Hz, 1.4A MAX, Output 15V DC 4.34A
Case Dimensions (Depth x Width x Height) 220mm x 275mm x 100mm
Weight 2.5kg
