Harrison Audio FleX-10 USB/ADAT Audio Interface

The Harrison Audio FleX-10 is a 10-in/12-out, 32-bit/192kHz USB-C audio interface built around two Harrison high-performance mic preamps, each featuring H Drive transformer saturation circuits derived from the legendary Harrison 32 Series consoles — the same analogue character behind landmark recordings by Led Zeppelin, Queen, ABBA, Michael Jackson, and countless others, and at the heart of leading studios from Nashville to New York’s EastSide Sound. Classic Harrison high-pass and low-pass filters on each channel provide immediate tone shaping at the source, while dedicated balanced insert points on both channels allow inline integration of outboard compressors, 500 Series modules, and hardware effects. Eight channels of ADAT I/O expand the system for larger sessions, MIDI I/O over 3.5mm TRS keeps hardware synthesizers and controllers connected, and front-panel VU meters add analogue visual feedback to the workflow. The FleX-10 ships with a full license for Harrison Mixbus 12 DAW and the Harrison Creator Pack software bundle.

Key Features

• 2 Harrison mic preamps with H Drive transformer saturation — high-performance Harrison-designed preamps with H Drive transformer circuits on each channel, delivering the smooth analogue saturation and harmonic character of the Harrison 32 Series consoles; switchable between clean, detailed recording and driven transformer colour; two front-panel Hi-Z instrument inputs allow direct connection of guitar, bass, and instrument-level sources
• Classic Harrison high-pass and low-pass filters — per channel — HPF and LPF designs derived directly from the Harrison 32 Series console; provide immediate, musical tone shaping at the preamp stage for carving space around sources before the signal reaches the DAW
• Balanced insert points — per channel — dedicated balanced insert send and return on both channels for inline integration of outboard compressors, Harrison 500 Series modules, and external hardware effects; insert send also functions as a direct output for tracking processed signals back to the DAW
• 2 independent monitor outputs with dedicated level controls — two main stereo outputs for flexible speaker monitoring configurations; independent level controls per output pair
• 2 high-current headphone outputs — dual independent headphone outputs for engineer and performer monitoring; independent mixes per output
• 8 channels of ADAT I/O — expands the FleX-10 for larger recording sessions or seamless integration with existing ADAT-equipped gear and preamp expanders
• MIDI I/O over 3.5mm TRS — connects synthesizers, drum machines, and MIDI controllers without a separate MIDI interface
• Front-panel VU meters — analogue-style VU meters provide real-time visual level feedback with the look and feel of a classic studio console
• 32-bit/192kHz converters — USB-C — next-generation converters for high-resolution capture; class-compliant plug-and-play on Mac OS; ASIO driver included for Windows
• Harrison Mixbus 12 DAW and Creator Pack included — full license for Harrison Mixbus 12, the analogue console-inspired DAW with Harrison signature console EQ on every channel; Creator Pack includes premium virtual instruments, plug-ins, loops, and samples from Solid State Logic, Slate Digital, Sonible, Loopcloud, AAS, Native Instruments, IK Multimedia, and more

Specifications

• I/O Summary: 10-in/12-out
• Connectivity: USB-C
• Mic/Line Inputs: 2 × (Harrison mic preamps with H Drive)
• Instrument Inputs: 2 × Hi-Z (front panel)
• Line Inputs: 2 ×
• Insert Points: Balanced; per channel (channels 1 and 2)
• Filters: High-pass and low-pass; per channel (Harrison 32 Series-derived)
• Transformer Circuits: 2 × H Drive (one per channel)
• Monitor Outputs: 2 × stereo (dedicated level controls)
• Headphone Outputs: 2 × (high-current; independent)
• ADAT I/O: 8 channels
• MIDI: In/Out (3.5mm TRS)
• Metering: Front-panel VU meters
• Bit Depth: 32-bit
• Sample Rate: Up to 192kHz
• Mac Compatibility: Class-compliant; plug-and-play
• Windows Compatibility: ASIO driver included
• Included Software: Harrison Mixbus 12 DAW (full license); Harrison Creator Pack (SSL; Slate Digital; Sonible; Loopcloud; AAS; Native Instruments; IK Multimedia; and more)
