Quested V3110 Three-Way Active Studio Monitor

The V3110 delivers critical full-range high-powered monitoring for midfield applications in larger spaces or as main monitors in smaller rooms. The direct successor to the VS3208, this three-way design is simultaneously one of Quested’s largest self-powered monitors and currently their smallest three-way model. A 10-inch low-frequency driver paired with 3-inch soft-dome mid and 1.18-inch soft-dome high-frequency units extends bass response down to 30Hz while delivering 115dB continuous SPL (123dB music peak). Hybrid onboard Class AB and Class D amplification totals 1000 watts, making the V3110 the most powerful in its class with remarkable sonic resemblance to Quested’s larger systems. The rotatable mid-high baffle enables vertical or horizontal mounting for versatile placement, while 24dB/octave crossovers at 650Hz and 2.5kHz ensure seamless driver integration. Configurable as standalone monitors or as part of multichannel surround and immersive systems.

Key Features:

• 1000-Watt Hybrid Amplification: Onboard Class AB and Class D power delivers over 700W to the LF driver and 150W each to mid and high frequencies, making the V3110 the most powerful in its class with exceptional headroom.
• Three-Way Design with Extended Bass: 10-inch LF driver, 3-inch soft-dome mid, and 1.18-inch soft-dome tweeter deliver accurate full-range monitoring from 30Hz (-6dB) to 20kHz with immersive soundstage presentation.
• High SPL Capability: 115dB continuous pink noise SPL with 123dB music peak output enables confident monitoring in demanding midfield applications without compression or distortion.
• Rotatable Mid-High Baffle: Unique design allows vertical or horizontal mounting orientation, providing placement flexibility for various studio configurations and console positions.
• Precision Crossover Design: 24dB/octave slopes at 650Hz and 2.5kHz ensure seamless integration between drivers with variable LF, mid, and HF EQ adjustments for room optimization.
• Flexible Sensitivity Calibration: Rear-mounted 10-position rotary switch provides 2dB-step adjustment from +4dBu to -14dBu for precise level matching in stereo and multichannel configurations.
• Multichannel System Ready: Configurable as standalone monitors or integrated into surround sound and immersive monitoring systems with sonic resemblance to Quested’s larger reference systems.

Specifications

• Type: Three-way active studio monitor
• Low-Frequency Driver: 1 × 250mm (10″) cone
• Mid-Frequency Driver: 1 × 76mm (3″) soft dome
• High-Frequency Driver: 1 × 28mm (1.18″) soft dome
• Amplification: Hybrid Class AB + Class D, 1000W total
• LF Amplifier Power: >700W RMS continuous
• MF Amplifier Power: >150W RMS continuous
• HF Amplifier Power: >150W RMS continuous
• Maximum SPL: 115dB continuous (pink noise), 123dB peak (music)
• Frequency Response: 34Hz – 20kHz (±2dB), 30Hz (-6dB)
• Crossover Points: 650Hz, 2.5kHz (24dB/octave)
• THD: Typical 0.03% @ 1kHz up to 1dB below clip, typical 0.005% @ 20W RMS 1kHz
• Hum & Noise: >-100dB referred to clip
• EQ Adjustments: LF (Flat, -6dB below 100Hz, +3dB/+4dB above 80Hz), Mid (Flat ±1dB 650Hz–2.5kHz), HF (Flat ±1dB 2.5kHz–40kHz)
• Protective Filters: Lower (-3dB @ 14Hz, 24dB/octave), Upper (-3dB @ 75kHz, 24dB/octave)
• Input Connector: XLR and 1/4″ jack combo socket
• Input Impedance: 10kΩ electronically balanced
• Sensitivity Range: +4dBu to -14dBu for 100dB SPL @ 1m (10-position rotary, 2dB steps)
• Indicators: Blue LED (power on/warming up), Red LED (clip warning 1dB before amplifier clip)
• Power Requirements: 115V or 230V @ 50-60Hz (internal plug selectable)
• Power Consumption: 72W quiescent, 110W typical (average music), 195W maximum @ 230VAC
• Baffle Orientation: Rotatable mid-high section (vertical or horizontal mounting)
• Dimensions (W × H × D): 380mm × 600mm × 360mm (15″ × 23.75″ × 14.25″)
• Weight: 39kg (86 lbs)
• Predecessor Model: VS3208
• Warranty: 5-year manufacturer warranty
• Recommended Applications: Midfield monitoring in larger spaces, main monitors in smaller rooms, surround sound systems, immersive audio configurations, critical full-range monitoring
