Royer dBooster2: Dual-Channel In-Line Gain Booster and DI

The Royer Labs dBooster2 is an advanced dual-channel in-line gain booster and DI (Direct Input) designed to provide versatile and high-quality gain for recording purposes. Building upon the features of the original dBooster, the dBooster2 introduces dual independent channels, each of which doubles as a high-quality DI for electric guitars and bass. This flexibility allows users to connect two microphones simultaneously, use both channels for DI applications, or mix and match a microphone with a DI input.

The Royer Labs dBooster2 is a versatile and advanced tool for audio professionals, providing dual-channel in-line gain boosting and high-quality DI capabilities for a wide range of recording applications.

Key Features

• Dual Channels: Two independent channels, each capable of providing in-line gain for microphones or serving as a high-quality DI for electric guitars and bass.
• Adjustable Gain Settings (Microphone Mode): Switch between 12 dB and 20 dB of gain depending on the recording needs.
• Adjustable Gain Settings (DI Mode): Select 0 dB (unity) gain or switch to 8 dB of gain for electric guitars and bass in DI mode.
• Dual Class A Input Stages: Delivers crystal clean gain with minimal noise and self-distortion through dual Class A input stages.
• Low-Impedance Output: Maintains signal integrity in both studio and live settings, capable of driving long cable lengths and handling challenging loads.
• Compatibility with Royer Microphones: Optimized for use with Royer R-121s, R-10s, and stereo SF-12s, also suitable for dynamic microphones like the SM7.
• Built in the USA: Proudly built in the USA and shipped from Royer Labs’ headquarters in Burbank, California.

Applications

• Dual Microphone Recording: Enables simultaneous use of two microphones, allowing for various recording techniques and capturing different sonic perspectives.
• Microphone and DI Combinations: Provides flexibility in recording scenarios by connecting a microphone to one channel and a DI input to another.
• Adjustable Gain for Microphones: Boosts the signal of softer instruments and singers or prevents overloading during high-volume performances.
• DI Applications: Serves as a high-quality DI for electric guitars and bass, with adjustable gain to accommodate different instruments and playing styles.

• Gain: Switchable 12dB or 20dB in Mic mode, 0dB or 8dB in DI mode.
• THD+N: At 20dB Gain – .0015%, at 12dB Gain – .001%.
• IM Distortion: Less than .002% at 20dB setting, less than .005% at 12dB setting.
• Self-Noise: 20dB setting less than 11dBa, 12dB setting less than 15dBa.
• Headroom: 127dB at 20dB setting, 120dB at 12dB setting.
• Frequency Response: 20Hz-20kHz +/- .25dB.
• Input Impedance: 3.6K-Ohm in Mic mode, 270K-Ohm in DI mode.
• Output Impedance: 300-Ohms at 20dB setting.
• Current Draw: Approximately 5mA at zero signal and 7.5mA at full output.
• Input and Output Connections: Balanced XLR (Pin 1 Ground, Pin 2 Signal Hot, Pin 3 Signal Cold), HI-Z (DI) ¼-inch unbalanced, tip signal HOT.
• Power: 48-Volt phantom.
• Dimensions: 3.875” L X 3.875” W X 1.75” H.
• Weight: 10.2 oz (289g).
