Tube-Tech ME 1B – Classic Passive Tube Midrange Equalizer

The Tube-Tech ME 1B is an all-tube, passive midrange equalizer inspired by the legendary Pultec MEQ-5. Featuring two boost sections and one dip section, it provides an ultra-smooth, musical approach to midrange shaping. With its broad bandwidth and warm tonal characteristics, the ME 1B is a perfect choice for vocals, instruments, and bus processing.

Legendary Midrange Shaping

Midrange frequencies are crucial for achieving balance in a mix. The Tube-Tech ME 1B enhances the midrange with the classic warmth of passive equalization, delivering a natural, open sound free of harshness—even at extreme boost settings. Whether used on individual tracks or across a mix bus, the ME 1B is a must-have for achieving a polished and musical midrange.

Key Features

• All-Tube Passive Midrange EQ – Smooth, musical equalization
• Dual Boost & Single Dip Sections – Flexible frequency shaping
• Broad Bandwidth Design – Enhances midrange clarity without harshness
• Transformer-Balanced Input & Output – Ensures pristine signal integrity
• No Insertion Loss – Maximum signal preservation
• Push-Pull Tube Amplifier – Restores gain with rich analog warmth
• Perfect Companion for PE 1C – Ideal for vocal, instrument, and bus EQ

Technical Specifications

• Frequency Response (-3 dB): 5 Hz – 40 kHz
• Low Noise: < -80 dBU at 0 dB gain
• CMRR: > 60 dB at 10 kHz
• Low Frequency Peaks: 0.2, 0.3, 0.5, 0.7, 1 kHz (0 to +10 dB)
• Midrange Frequency Dips: 0.2, 0.3, 0.5, 0.7, 1, 1.5, 2, 3, 4, 5, 7 kHz (0 to -10 dB)
• High Frequency Peaks: 1.5, 2, 3, 4, 5 kHz (0 to +8 dB)
• Input Impedance: 600Ω
• Insertion Loss: None

How Does the ME 1B Sound?

The Tube-Tech ME 1B adds warmth and depth to midrange frequencies, making it a staple for engineers looking to refine vocals, instruments, and full mixes. The passive filter design ensures smooth, natural tonal shaping, making it a vital tool for any professional studio.
